Product Details
＋
DESCRIPTION
- JET Trademaster Series electric hoists combines safety, portability, and durability to operate in all your industrial, construction, and transportation applications. With its market leading wireless controller and 2 in 1 mechanical brake and overload slip clutch, safety is most important. With the only DC Brushless motor in the market, 5 pocket chain sheave, and thermal overload protection, you have the durability you need to reduce maintenance costs. All of this with a lightweight compact housing that will get you into those tight areas while allowing you transport it from job to job in its molded carrying case. The Tradesmaster Series comes in 1/8Ton to 2Ton capacities and standard lifts of 10 and 20ft. (custom lifts up to 100ft are available)
FEATURES
- 1/8 to 1/2 ton models come in plastic carry case for exceptional mobility
- 30 / 7.5 Time ratings
- Comes standard with Wireless Controller that can infinitely adjust speed from creep to 4ft/min with speed dial and max of 41ft/min in high speed
- DC Brushless motor designed for a longer lifespan than normal Electric Hoist motors reducing maintenance costs
- Electronic controls have protections on them with 10 failure codes that are shown on wireless pendant for troubleshooting
- Low noise at less than 75 dBA
- Overload protection using slip clutch system to protect hoist from loads over rated capacities
- Single phase 120V plug enables use in all areas and the Permanent Magnet Brushless Motor has the lowest required starting current available at just 10amp.
- TAA Approved
SPECIFICATIONS
- Capacity (Lbs.): 550
- Load Capacity (Tons): 1/4
- Lift (Ft.): 20
- Overload Protection: Yes
- Duty Cycle Rating: H3
- Duty Cycle (%): 30
- Max. On Time (Min. / Hr.): 30
- Weight (Lbs.): 38.6
- Max. Number of Starts (Per Hr.): 180
- Lifting Speed (FPM): 0-10 / 41
- Motor (HP): 0.8HP, 120V, 1PH
- Motor Phase: Single
- Motor Voltage (V.): 120
